How to: Setting Up Nextcloud on Raspberry Pi: SSL, Advanced App Support, High-Performance PostgreSQL, and Cloudflare Zero Trust Integration

Step 1: Docker Compose Configuration

First, create a docker-compose.yml file with the following configuration:

Here /mnt/ad/nextcloud is the folder path of the external HDD in my Raspberry Pi. You can change this path.

version: '3'
services:  db:    image: postgres:alpine    restart: always    volumes:      - db:/var/lib/postgresql/data:Z    env_file:      - db.env    environment:      - PUID=109      - PGID=65534    networks:      - proxy-tier
  cache:    image: redis:6.2-alpine    restart: always    ports:      - '6379:6379'    command: redis-server --save 20 1    volumes:       - cache:/data    networks:      - proxy-tier
  app:    #image: nextcloud:fpm-alpine    build:      context: .      dockerfile: Dockerfile.app    container_name: nextcloud    restart: always    volumes:      - nextcloud:/var/www/html:z      - /mnt/ad/nextcloud:/extdata      - php-fpm:/usr/local/etc      - type: tmpfs        target: /tmp:exec    environment:      - POSTGRES_HOST=db      - REDIS_HOST=cache      - PHP_MEMORY_LIMIT=2048M    env_file:      - db.env    depends_on:      - db      - cache    devices:      - /dev/video10:/dev/video10      - /dev/video11:/dev/video11      - /dev/video12:/dev/video12    networks:      - proxy-tier
  cron:    #image: nextcloud:fpm-alpine    build:      context: .      dockerfile: Dockerfile.cron    restart: always    volumes:      - nextcloud:/var/www/html:z      - /mnt/ad/nextcloud:/extdata      - php-fpm:/usr/local/etc      - type: tmpfs        target: /tmp:exec    entrypoint: /cron.sh    depends_on:      - db      - cache    devices:      - /dev/video10:/dev/video10      - /dev/video11:/dev/video11      - /dev/video12:/dev/video12    environment:      - PHP_MEMORY_LIMIT=2048M    networks:      - proxy-tier   imaginary:    image: ghcr.io/italypaleale/imaginary:master    container_name: imaginary    restart: always    ports:      - '9000:9000'    command: -enable-url-source   nginx-proxy:    image: nginx:alpine    container_name: nginx-proxy    ports:      - "8443:443"    volumes:      - sslcerts:/etc/nginx/ssl      - ./nginx.conf:/etc/nginx/nginx.conf      - nextcloud:/var/www/html:z,ro    networks:      - proxy-tier    depends_on:      - app

volumes:  db:  php-fpm:  nextcloud:  sslcerts:  cache:    driver: local
networks:  proxy-tier:

Step 2: Dockerfile Configuration [Dockerfile.app]

Create a Dockerfile.app with the following content:

# Use the official Nextcloud image as a base image FROM nextcloud:stable-fpm-alpine
# Install build essentials RUN apk update && \    apk add --no-cache build-base
# Install imagemagick-common and ffmpeg RUN apk add --no-cache ffmpeg \    && apk add --no-cache nodejs npm \    && apk add --no-cache util-linux \    && apk add --no-cache git g++ cmake ghostscript libx11-dev sudo nano
# Set the NODE_PATH environment variable to point to the Node.js binary ENV NODE_PATH /usr/bin/node ENV NICE_CMD /usr/bin/nice
RUN git clone https://github.com/davisking/dlib.git \ && cd dlib/dlib \ && mkdir build \ && cd build \ && cmake -DBUILD_SHARED_LIBS=ON .. \ && make \ && make install
RUN git clone https://github.com/goodspb/pdlib.git /usr/src/php/ext/pdlib
RUN docker-php-ext-install pdlib
# Install BZip2 library and development files RUN apk add --no-cache bzip2-dev
# Install php-bz2 RUN docker-php-ext-install bz2
# Install smbclient RUN apk add --no-cache samba-client
# Clean up unnecessary build dependencies RUN apk del build-base cmake git

Step 3: Dockerfile Configuration [Dockerfile.cron]

Create a Dockerfile.cron with the following content:

# Use the official Nextcloud image as a base image FROM nextcloud:stable-fpm-alpine
# Install build essentials RUN apk update && \    apk add --no-cache build-base
# Install imagemagick-common and ffmpeg RUN apk add --no-cache ffmpeg \    && apk add --no-cache nodejs npm \    && apk add --no-cache util-linux \    && apk add --no-cache git g++ cmake ghostscript libx11-dev sudo nano
# Set the NODE_PATH environment variable to point to the Node.js binary ENV NODE_PATH /usr/bin/node ENV NICE_CMD /usr/bin/nice
RUN git clone https://github.com/davisking/dlib.git \ && cd dlib/dlib \ && mkdir build \ && cd build \ && cmake -DBUILD_SHARED_LIBS=ON .. \ && make \ && make install
RUN git clone https://github.com/goodspb/pdlib.git /usr/src/php/ext/pdlib
RUN docker-php-ext-install pdlib
# Install BZip2 library and development files RUN apk add --no-cache bzip2-dev
# Install php-bz2 RUN docker-php-ext-install bz2
# Install smbclient RUN apk add --no-cache samba-client
# Clean up unnecessary build dependencies RUN apk del build-base cmake git

Step 4: Generating SSL/TLS Certificates and Diffie-Hellman Parameters

Execute the following commands in your terminal to generate SSL/TLS certificates and Diffie-Hellman parameters:

You don’t have to write anything for the certificate generation, just press the enter key

cd ~
sudo mkdir nextcloud/certs
cd nextcloud/certs
sudo su
openssl genrsa -out mycloud.example.com.key 2048 openssl req -x509 -new -nodes -key mycloud.example.com.key -sha256 -days 365 -out myCA.pem
openssl req -new -key mycloud.example.com.key -out mycloud.example.com.csr openssl x509 -req -in mycloud.example.com.csr -CA myCA.pem -CAkey mycloud.example.com.key -CAcreateserial -out mycloud.example.com.crt -days 365 -sha256
openssl dhparam -out dhparam.pem 2048

Step 5: Create a db.env file at /home/pi/nextcloud

POSTGRES_PASSWORD=somesecurepassword
POSTGRES_DB=nextcloud
POSTGRES_USER=nextcloud

Step 6: Create nginx.conf file at /home/pi/nextcloud

worker_processes auto;
error_log  /var/log/nginx/error.log warn; pid        /var/run/nginx.pid;

events {    worker_connections  10024; }

http {    include       /etc/nginx/mime.types;    default_type  application/octet-stream;     log_format  main  '$remote_addr - $remote_user [$time_local] "$request" '                      '$status $body_bytes_sent "$http_referer" '                      '"$http_user_agent" "$http_x_forwarded_for"';     access_log  /var/log/nginx/access.log  main;     sendfile        on;    #tcp_nopush     on;     # Prevent nginx HTTP Server Detection    server_tokens   off;     keepalive_timeout  65;     #gzip  on;     upstream php-handler {        server app:9000;    }     server {        listen 80;         # HSTS settings        # WARNING: Only add the preload option once you read about        # the consequences in https://hstspreload.org/. This option        # will add the domain to a hardcoded list that is shipped        # in all major browsers and getting removed from this list        # could take several months.        #add_header Strict-Transport-Security "max-age=15768000; includeSubDomains; preload;" always;         # set max upload size        client_max_body_size 512M;        fastcgi_buffers 64 4K;         # Enable gzip but do not remove ETag headers        gzip on;        gzip_vary on;        gzip_comp_level 4;        gzip_min_length 256;        gzip_proxied expired no-cache no-store private no_last_modified no_etag auth;        gzip_types application/atom+xml application/javascript application/json application/ld+json application/manifest+json application/rss+xml application/vnd.geo+json application/vnd.ms-fontobject application/x-font-ttf application/x-web-app-manifest+json application/xhtml+xml application/xml font/opentype image/bmp image/svg+xml image/x-icon text/cache-manifest text/css text/plain text/vcard text/vnd.rim.location.xloc text/vtt text/x-component text/x-cross-domain-policy;         # Pagespeed is not supported by Nextcloud, so if your server is built        # with the `ngx_pagespeed` module, uncomment this line to disable it.        #pagespeed off;         # HTTP response headers borrowed from Nextcloud `.htaccess`        add_header Referrer-Policy                      "no-referrer"       always;        add_header X-Content-Type-Options               "nosniff"           always;        add_header X-Download-Options                   "noopen"            always;        add_header X-Frame-Options                      "SAMEORIGIN"        always;        add_header X-Permitted-Cross-Domain-Policies    "none"              always;        add_header X-Robots-Tag                         "noindex, nofollow" always;        add_header X-XSS-Protection                     "1; mode=block"     always;         # Remove X-Powered-By, which is an information leak        fastcgi_hide_header X-Powered-By;         # Path to the root of your installation        root /var/www/html;         # Specify how to handle directories -- specifying `/index.php$request_uri`        # here as the fallback means that Nginx always exhibits the desired behaviour        # when a client requests a path that corresponds to a directory that exists        # on the server. In particular, if that directory contains an index.php file,        # that file is correctly served; if it doesn't, then the request is passed to        # the front-end controller. This consistent behaviour means that we don't need        # to specify custom rules for certain paths (e.g. images and other assets,        # `/updater`, `/ocm-provider`, `/ocs-provider`), and thus        # `try_files $uri $uri/ /index.php$request_uri`        # always provides the desired behaviour.        index index.php index.html /index.php$request_uri;         # Rule borrowed from `.htaccess` to handle Microsoft DAV clients        location = / {            if ( $http_user_agent ~ ^DavClnt ) {                return 302 /remote.php/webdav/$is_args$args;            }        }         location = /robots.txt {            allow all;            log_not_found off;            access_log off;        }         # Make a regex exception for `/.well-known` so that clients can still        # access it despite the existence of the regex rule        # `location ~ /(\.|autotest|...)` which would otherwise handle requests        # for `/.well-known`.        location ^~ /.well-known {            # The rules in this block are an adaptation of the rules            # in `.htaccess` that concern `/.well-known`.             location = /.well-known/carddav { return 301 /remote.php/dav/; }            location = /.well-known/caldav  { return 301 /remote.php/dav/; }             location /.well-known/acme-challenge    { try_files $uri $uri/ =404; }            location /.well-known/pki-validation    { try_files $uri $uri/ =404; }             # Let Nextcloud's API for `/.well-known` URIs handle all other            # requests by passing them to the front-end controller.            return 301 /index.php$request_uri;        }         # Rules borrowed from `.htaccess` to hide certain paths from clients        location ~ ^/(?:build|tests|config|lib|3rdparty|templates|data)(?:$|/)  { return 404; }        location ~ ^/(?:\.|autotest|occ|issue|indie|db_|console)                { return 404; }         # Ensure this block, which passes PHP files to the PHP process, is above the blocks        # which handle static assets (as seen below). If this block is not declared first,        # then Nginx will encounter an infinite rewriting loop when it prepends `/index.php`        # to the URI, resulting in a HTTP 500 error response.        location ~ \.php(?:$|/) {            # Required for legacy support            rewrite ^/(?!index|remote|public|cron|core\/ajax\/update|status|ocs\/v[12]|updater\/.+|oc[ms]-provider\/.+|.+\/richdocumentscode\/proxy) /index.php$request_uri;             fastcgi_split_path_info ^(.+?\.php)(/.*)$;            set $path_info $fastcgi_path_info;             try_files $fastcgi_script_name =404;             include fastcgi_params;            fastcgi_param SCRIPT_FILENAME $document_root$fastcgi_script_name;            fastcgi_param PATH_INFO $path_info;            #fastcgi_param HTTPS on;             fastcgi_param modHeadersAvailable true;         # Avoid sending the security headers twice            fastcgi_param front_controller_active true;     # Enable pretty urls            fastcgi_pass php-handler;             fastcgi_intercept_errors on;            fastcgi_request_buffering off;        }         location ~ \.(?:css|js|svg|gif)$ {            try_files $uri /index.php$request_uri;            expires 6M;         # Cache-Control policy borrowed from `.htaccess`            access_log off;     # Optional: Don't log access to assets        }         location ~ \.woff2?$ {            try_files $uri /index.php$request_uri;            expires 7d;         # Cache-Control policy borrowed from `.htaccess`            access_log off;     # Optional: Don't log access to assets        }         # Rule borrowed from `.htaccess`        location /remote {            return 301 /remote.php$request_uri;        }         location / {            try_files $uri $uri/ /index.php$request_uri;        }    }
        server {        listen 443 ssl;         ssl_certificate /etc/nginx/ssl/cert.pem;        ssl_certificate_key /etc/nginx/ssl/key.pem;         ssl_protocols TLSv1.2 TLSv1.3;        ssl_prefer_server_ciphers off;         ssl_dhparam /etc/nginx/ssl/dhparam.pem;         ssl_ciphers TLS_AES_256_GCM_SHA384:TLS_CHACHA20_POLY1305_SHA256:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-RSA-AES128-GCM-SHA256:DHE-RSA-AES256-GCM-SHA384:DHE-RSA-AES128-GCM-SHA256;         ssl_ecdh_curve secp384r1;        ssl_session_timeout  10m;        ssl_session_cache shared:SSL:10m;        ssl_session_tickets off;         resolver 8.8.8.8 8.8.4.4 valid=300s;        resolver_timeout 5s;         add_header Strict-Transport-Security "max-age=63072000; includeSubDomains; preload";
        # HSTS settings        # WARNING: Only add the preload option once you read about        # the consequences in https://hstspreload.org/. This option        # will add the domain to a hardcoded list that is shipped        # in all major browsers and getting removed from this list        # could take several months.        #add_header Strict-Transport-Security "max-age=15768000; includeSubDomains; preload;" always;         # set max upload size        client_max_body_size 512M;        fastcgi_buffers 64 4K;         # Enable gzip but do not remove ETag headers        gzip on;        gzip_vary on;        gzip_comp_level 4;        gzip_min_length 256;        gzip_proxied expired no-cache no-store private no_last_modified no_etag auth;        gzip_types application/atom+xml application/javascript application/json application/ld+json application/manifest+json application/rss+xml application/vnd.geo+json application/vnd.ms-fontobject application/x-font-ttf application/x-web-app-manifest+json application/xhtml+xml application/xml font/opentype image/bmp image/svg+xml image/x-icon text/cache-manifest text/css text/plain text/vcard text/vnd.rim.location.xloc text/vtt text/x-component text/x-cross-domain-policy;         # Pagespeed is not supported by Nextcloud, so if your server is built        # with the `ngx_pagespeed` module, uncomment this line to disable it.        #pagespeed off;         # HTTP response headers borrowed from Nextcloud `.htaccess`        add_header Referrer-Policy                      "no-referrer"       always;        add_header X-Content-Type-Options               "nosniff"           always;        add_header X-Download-Options                   "noopen"            always;        add_header X-Frame-Options                      "SAMEORIGIN"        always;        add_header X-Permitted-Cross-Domain-Policies    "none"              always;        add_header X-Robots-Tag                         "noindex, nofollow" always;        add_header X-XSS-Protection                     "1; mode=block"     always;         # Remove X-Powered-By, which is an information leak        fastcgi_hide_header X-Powered-By;         # Path to the root of your installation        root /var/www/html;         # Specify how to handle directories -- specifying `/index.php$request_uri`        # here as the fallback means that Nginx always exhibits the desired behaviour        # when a client requests a path that corresponds to a directory that exists        # on the server. In particular, if that directory contains an index.php file,        # that file is correctly served; if it doesn't, then the request is passed to        # the front-end controller. This consistent behaviour means that we don't need        # to specify custom rules for certain paths (e.g. images and other assets,        # `/updater`, `/ocm-provider`, `/ocs-provider`), and thus        # `try_files $uri $uri/ /index.php$request_uri`        # always provides the desired behaviour.        index index.php index.html /index.php$request_uri;         # Rule borrowed from `.htaccess` to handle Microsoft DAV clients        location = / {            if ( $http_user_agent ~ ^DavClnt ) {                return 302 /remote.php/webdav/$is_args$args;            }        }         location = /robots.txt {            allow all;            log_not_found off;            access_log off;        }         # Make a regex exception for `/.well-known` so that clients can still        # access it despite the existence of the regex rule        # `location ~ /(\.|autotest|...)` which would otherwise handle requests        # for `/.well-known`.        location ^~ /.well-known {            # The rules in this block are an adaptation of the rules            # in `.htaccess` that concern `/.well-known`.             location = /.well-known/carddav { return 301 /remote.php/dav/; }            location = /.well-known/caldav  { return 301 /remote.php/dav/; }             location /.well-known/acme-challenge    { try_files $uri $uri/ =404; }            location /.well-known/pki-validation    { try_files $uri $uri/ =404; }             # Let Nextcloud's API for `/.well-known` URIs handle all other            # requests by passing them to the front-end controller.            return 301 /index.php$request_uri;        }         # Rules borrowed from `.htaccess` to hide certain paths from clients        location ~ ^/(?:build|tests|config|lib|3rdparty|templates|data)(?:$|/)  { return 404; }        location ~ ^/(?:\.|autotest|occ|issue|indie|db_|console)                { return 404; }         # Ensure this block, which passes PHP files to the PHP process, is above the blocks        # which handle static assets (as seen below). If this block is not declared first,        # then Nginx will encounter an infinite rewriting loop when it prepends `/index.php`        # to the URI, resulting in a HTTP 500 error response.        location ~ \.php(?:$|/) {            # Required for legacy support            rewrite ^/(?!index|remote|public|cron|core\/ajax\/update|status|ocs\/v[12]|updater\/.+|oc[ms]-provider\/.+|.+\/richdocumentscode\/proxy) /index.php$request_uri;             fastcgi_split_path_info ^(.+?\.php)(/.*)$;            set $path_info $fastcgi_path_info;             try_files $fastcgi_script_name =404;             include fastcgi_params;            fastcgi_param SCRIPT_FILENAME $document_root$fastcgi_script_name;            fastcgi_param PATH_INFO $path_info;            #fastcgi_param HTTPS on;             fastcgi_param modHeadersAvailable true;         # Avoid sending the security headers twice            fastcgi_param front_controller_active true;     # Enable pretty urls            fastcgi_pass php-handler;             fastcgi_intercept_errors on;            fastcgi_request_buffering off;        }         location ~ \.(?:css|js|svg|gif)$ {            try_files $uri /index.php$request_uri;            expires 6M;         # Cache-Control policy borrowed from `.htaccess`            access_log off;     # Optional: Don't log access to assets        }         location ~ \.woff2?$ {            try_files $uri /index.php$request_uri;            expires 7d;         # Cache-Control policy borrowed from `.htaccess`            access_log off;     # Optional: Don't log access to assets        }         # Rule borrowed from `.htaccess`        location /remote {            return 301 /remote.php$request_uri;        }         location / {            try_files $uri $uri/ /index.php$request_uri;        }    } }

Step 7: Copy/Create files at

/var/lib/docker/volumes/nextcloud_sslcerts/_data
